Technical Data
For more details please choose a filter.
| Dimension in mm | Part Number | order request | ||||
|---|---|---|---|---|---|---|
| Wind E x F | ØB | C | D | SW | ||
| M3x16 | 2 | 16.5 | 35.5 | 4 | 3502001 | Request |
| M4x20 | 3 | 16.5 | 40 | 5 | 3503001 | Request |
| M5x25 | 4 | 19.5 | 48.5 | 6 | 3504001 | Request |
| M5x25 | 5 | 19.5 | 48.5 | 7 | 3505001 | Request |
| M6x28 | 6 | 19.5 | 51.5 | 8 | 3506001 | Request |
| M8x36 | 8 | 34 | 75 | 11 | 3508001 | Request |
| M10x42 | 10 | 34 | 81 | 13 | 3510001 | Request |
| M12x48 | 12 | 34 | 87 | 13 | 3512001 | Request |
| M14x50 | 14 | 38 | 95 | 17 | 3514001 | Request |
| M16x58 | 16 | 38 | 103 | 19 | 3516001 | Request |
| M16x58 | 18 | 42 | 107 | 22 | 3518001 | Request |
| M18x70 | 20 | 42 | 119 | 24 | 3520001 | Request |
| M20x74 | 25 | 62 | 145 | 32 | 3525001 | Request |
| M24/2x81 | 30 | 62 | 152 | 36 | 3530001 | Request |
| M30/2x90 | 35 | 62 | 162 | 41 | 3535001 | Request |
| M36/3x105 | 40 | 62 | 178 | 46 | 3540001 | Request |
